The Nexo PS-8 Loudspeaker System is the latest addition to Nexos acclaimed PS Series; versatile, compact, full-range loudspeakers tailored for a wide range of touring an installed sound reinforcement applications. Like all Nexo products, the PS8 loudspeaker and optional LS400 Subwoofer are designed to work with advanced electronic processors, guaranteeing consistent performance and reliability of the highest standard.

The Nexo LS400 Subwoofer extends the usable range of the PS8 Loudspeaker to 40 Hz, providing high performance, high power output (131 dB Peak) in an extremely compact, light weight package. The new Nexo designed shielded Neodymium 12" driver makes the LS400 usable next to sensitive video equipment. The PS8 TD’s integral sub section and combined signal (PS8 and LS400) Speakon wiring ensure cost effective and simple system implementation.

Nexo PS-8TD Active Controller for PS-* and LS400

The PS8 TD Controller is an advanced analogue processor that allows the PS8 Loudspeaker and optional LS400 Subwoofer to achieve exceptional performance from such compact packages. The PS8 TD provides crossover, sensed amplifier control and system equalisation optimised for the PS8 and LS400. One PS8 TD has two inputs and three outputs, L, R and summed sub out, minimising installation cost and complexity.

Nexo PS-8 Accessories,   PS-8 MB-1 (Nexo code FS0081-001) Primary mounting block assembly with 2 M10 captive nuts

Nexo PS-8 Accessories, PS-8 MB2 (Nexo code FS0081-002) Multipurpose L Bracket

Nexo PS-8 Accessories, PS-8 MB3 (Nexo code FS0081-003) Stand/mast adaptor

Nexo PS-8 Accessories, PS-8 MB4 (Nexo code FS0081-004) Installation U Bracket

Nexo PS-8 Accessories, PS-8 EB (Nexo code SA0081-002) Eyebolt (Pack of 10) For attachment of secondary safety wires

Nexo PS-8 Accessories, PS-8 SW (Nexo code SA0081-001) Safety Wire for Grill

The Nexo PS10 Loudspeaker can be safely driven with over 500 Watts of amplifier power, yet is only half the weight and volume of standard trapezoidal systems. The dispersion, architecture and weight balance of the PS10 Loudspeaker are designed to provide both exceptional PA and stage monitor performance from a single product without compromise. The 2-way passive 8Ohm design uses a single amp channel to deliver bi-amped performance for less money, space and complexity.

The Nexo LS500 Subwoofer extends the usable range of the PS10 Loudspeaker to 38 Hz, providing high performance and high power output (134 dB Peak) in an extremely compact, light weight package. The PS10 TDController’s integral sub section and combined signal (PS10 and LS500) Speakon wiring ensure cost effective and simple system implementation. One LS500 is typically used with 2 PS10 loudspeakers, additional units may be used for an enhanced effect.

Nexo PS-10TD Active Controller for PS-10 and LS-500

Nexo PS-10 / PS15 Accessories, FLY-LS1 Flying kit for single LS-500 or LS1200

Nexo PS-10 Accessories, FLYPS-10 Flying kit. 1 track, 2 cups, 4 clamps- single PS-10

Nexo PS-10 Accessories, STD-PS Mounting pole for mounting PS-10/15 on top of LS subwoofer

Nexo PS-10 Accessories, UPS-10 "U" bracket only for PS-10

Nexo PS-10 Accessories, STDUPS-10 "U" bracket and mounting pole (UPS-10 and STDPS)

The Nexo PS15 Loudspeaker can be safely driven with over 1000 Watts of amplifier power, yet it has a small volume and reduced weight. The dispersion, architecture and weight balance of the PS15 Loudspeaker are designed to provide both exceptional PA and stage monitor performance from a single product without compromise. The 2-way passive 8Ohm design uses a single amplifier channel in passive mode to deliver bi-amped performance for less money, space and complexity.

The Nexo PS-15BASS is a passive box which can be simply linked in parallel with a PS-15 or run off a separate amplifier post the controller. It is not intended as a true sub, so it provides low frequency extension and punch in the situations where very low frequencies are not required. When used in conjunction with the LS-1200, it enhances overall system output. Dimensions differ from the PS-15 in depth (457mm) and the multiple angle is replaced by a trapzoid.

The Nexo LS1200 Subwoofer extends the usable range of the PS15 Loudspeaker to 29 Hz, providing high performance and high power output (135 dB Peak) in an extremely compact, light weight package. The PS15 TDController’s integral sub section and combined signal (PS15 and LS1200) Speakon wiring ensure cost effective and simple system implementation. One LS1200 is typically used with 2 PS15 loudspeakers, additional units may be used for an enhanced effect.

Nexo PS-15TD Active Controller for PS-15 and LS1200.

2 in, 3 out can be configured for conventional left/right with mono sub operation, or optionally in active mode to run a PS-15 and LS-1200 as a mono three way system. The ability to run the controller in either crossover or overlap mode is a major bonus in many applications.

Nexo PS-15 Accessories, FLYPS-15 Flying kit. 1 track, 2 cups, 4 clamps – single PS-15

Nexo NXAMP 4x1 Powered TD Controller, The NXAMP 4X1 Powered TDcontroller, output capacity of 4x1300W under 2 ohm; establishing the 4x1 model as one of the most versatile amplifiers ever to ever be produced. These models will permit the users to connect a large number of NEXO speaker systems while working on a platform that will maximize their performance. With the optional incorporation of the new generation EtherSound 100 hardware, the NXAMPs will additionally provide an unprecedented capability of Digital Audio networking and Control.

Nexo NXAMP 4x4 Powered TD Controller, The NXAMP 4X4 Powered TDcontroller, output capacity of 4x4000W under 2 ohm; establishing the 4x4 model as one of the most powerful amplifiers to ever be produced. These models will permit the users to connect a large number of NEXO speaker systems while working on a platform that will maximize their performance. With the optional incorporation of the new generation EtherSound 100 hardware, the NXAMPs will additionally provide an unprecedented capability of Digital Audio networking and Control.

The Nexo NX242 Digital TD Controller provides all the functions of the conventional Nexo analogue TD controllers combined with all the advantages of the latest digital technology. The Nexo NX242 is an uprated version of the now discontinued NX241. As with the 241, it provides crossover, sensed amplifier control and system alignment, along with peak limiter, displacement and temperature protection on every channel.

NEXO ANXTENSION-ES4 NXtension-ES4 Expander board, Improves NX242 processing capacities and adds Digital Inputs/Outputs plus remote control functions via the DigiGram Ethersound network. The Ethersound Interface provides 4 digital inputs and outputs (24bit/48KHz.)with digital audio distribution (64 channels) over Ethernet and ultimate low propagation delay allowing its use in the most demanding of live audio applications.

Nexo Alpha E-FC Full Range Cabinet, Carpeted version. Same dimensions as Alpha S2. 18" Long Excursion Driver, composite curve, folded horn; horn-loaded 10" mid and 3" voice coil HF driver with passive network. The Alpha E-F is a full-range cabinet in a one-box dedicated format suitable for both installation and live touring use.

Nexo Alpha E-FC Full Range Cabinet, Painted version. Same dimensions as Alpha S2. 18" Long Excursion Driver, composite curve, folded horn; horn-loaded 10" mid and 3" voice coil HF driver with passive network. The Alpha E-F is a full-range cabinet in a one-box dedicated format suitable for both installation and live touring use.

Nexo Alpha E-M Mid/Hi Cabinet, Carpeted version. Horn-loaded 10" mid and 3" voice coil HF driver with passive network. Just 1/3 the size of the E-F. Stacked with an Alpha-E B1-18, the E-M offers exactly the same design criteria as the E-F, but in a two-box configuration for maximum flexibility.

Nexo Alpha E-M Mid/Hi Cabinet, Painted version. Horn-loaded 10" mid and 3" voice coil HF driver with passive network. Just 1/3 the size of the E-F. Stacked with an Alpha-E B1-18, the E-M offers exactly the same design criteria as the E-F, but in a two-box configuration for maximum flexibility.

Nexo Alpha E B1-18, Painted version. 18" folded horn high-power bass enclosure. 18" Long Excursion Driver Composite curve. From rock tours to nightclubs, theatres to live venues the powerful, lightweight Alpha-E system brings Alpha technology to an even wider audience.  The E Series is available in two different user formats; the full range E-F or the E-M & B1-18 combination.

Nexo Alpha E AL.WB2 Wheelboard for E-F or S2 Cabnits, Front Fixing

Nexo Alpha E AL.WL0.6 Touring Lid fo E-M Cabinet

Nexo Alpha E AL.WB1.3 Wheelboard for B1-18 Cabinet

Nexo Alpha E AL.EMFR Rails & Fly Kit for E-F Cabinet

Nexo Alpha E AL.VFR Rails & Fly Kit for E-M Cabinet

Nexo Alpha E AL.EFFR Rails & Fly Kit for B1-18 Cabinet
