£115.10 (£132.37 Including VAT at 15%)

Traxon Switching System Power Supply 24v/13A

£500.01 (£575.01 Including VAT at 15%)

Traxon Butler Ethernet to DMX Gateway (1024 DMX Channels) with integrated replay unit.

The Butler is an Ethernet based replay unit with 1024 (2x 512) DMX channels and an exchangeable SD-Card memory. It can be used either as a live DMX output interface in combination with a PC running the programmer software or stand alone from its internal memory (requires USB dongle MM for show upload). Via 'Soft Patch' it is possible to assign two diffeent DMX lines or to have the same line repeated several times. The DMX signal is available from RJ45 connecters, a cost effective solution for use in architectural projects. For DMX output, also optional XLR adapters are available.

Up to 1024 DMx Channels can be replayed; there is no limit on the show size as everything depends on the size of the SD memory card used. In case of having a show with more than 2 DMX universes several Butler devices can be linked via Ethernet and Synchronized with each other during replay mode. The Integrated IR Receiver offers a very practical option to recall shows from any IR remote control. Optionally an e:com remote terminal can be used for show control.

Specification

General

• Function: Ethernet/DMX interface with replay unit
• Application Area: Standalone/Live
• Interface: Ethernet(LAN), e*net
• DMX Interface: 2x RJ45
• Display: 7 Segment LED
• IR Receiver: Standard RC5/Traxon IR receiver
• Memory: SD card (up to 2GB)

Live Mode

• DMX Channels Live: 1024 (Per Device)
• DMX Universes: 2

Stand Alone Cluster Mode

• DMX Channels Stand Alone Cluster: 1024 (512x2)
• Sync interface: e*net (LAN)

Show Recall

• Via IR Remote control: e*com Terminal

Technical

• Power Supply: 5-45vAC/vDC, 4W PoE Compliant
• Dimensions: 71x24x84mm
• Weight: 0.15kg
• Special Features: Robust case with anodized aluminum
