MOOD LIGHT Mirror 64PXL Wash, The MOOD LIGHT Mirror 64PXL Wash is a revolutionary lighting panel with 64 individually controllable pixels. The resulting Tile is an extremely multifunctional product that can be used to display a superb array of colors, shapes, images, moving text and video content. The unique surface of the Mirror becomes translucent when illuminated and is guaranteed to astound and mesmerize any witness of this miraculous transformation from mirror to lighting element. This innovative lighting medium opens a whole new array of undreamt lighting possibilities and is guaranteed to grab attention when the people’s reflections suddenly disappear in a sea of color and light. Being the prefect alternative for any mirror, the Tile is highly suitable for a vast range of locations: hotels, bars, shopping centers, in-store décor, interior/residential decoration, casinos, airports and more.

Specification

• FEATURES: 64 Pixel Mirror LED Panel with wash effect, RJ45 connection
• ACCESSORIES: Including: mounting kit, 1,5 m RJ-45 data cable, 5 m DC cable
• CONTROL OPTIONS: DMX 512
• ENVIRONMENT: Indoor
• BEAM ANGLE: Decorative light
• WEIGHT: Approx. 7 kg/15.4 lbs
• DIMENSIONS: 50 cm x 50 cm x 9.5 cm, 19.7" x 19.7" x 3.75"

*To run the 64PXL Wash Panels you will need DMX Control software - this can be downloaded from E-Cue  http://www.ecue.tv/english.html

The system is all based around a Computer with a Network card / Router and a small Switching hub.

This network then feeds a Butler Ethernet to DMX Gateway and with a 24V power supply is capable of driving 4 panels.
For every additional 4 panels you will need a Butler Ethernet to DMX Gateway and a 24V power supply.

You will then need to program the butlers using the DMX software as a live show.
You can also download via the Computer a program to the Butler units which then allow stand alone operation without the Computer, however the Ethernet network is still required to synchronise all the panels.






Related products:


Traxon Switching System Power Supply 24v/13A £135.24 Traxon Switching System Power Supply 24v/13A Find Out More

Traxon Butler Ethernet to DMX Gateway £587.51 Traxon Butler Ethernet to DMX Gateway (1024 DMX Channels) with integrated replay unit. The Butler is an Ethernet based replay unit with 1024 (2x 512) DMX channels and an exchangeable SD-Card memory. It can be used either as a live DMX output interface in combination with a PC running the programmer software or stand alone from its internal memory (requires USB dongle MM for show upload). Via 'Soft Patch' it is possible to assign two diffeent DMX lines or to have the same line repeated several times. The DMX signal is available from RJ45 connecters, a cost effective solution for use in architectural projects. For DMX output, also optional XLR adapters are available. Up to 1024 DMx Channels can be replayed; there is no limit on the show size as everything depends on the size of the SD memory card used. In case of having a show with more than 2 DMX universes several Butler devices can be linked via Ethernet and Synchronized with each other during replay mode. The Integrated IR Receiver offers a very practical option to recall shows from any IR remote control. Optionally an e:com remote terminal can be used for show control. Specification General Function: Ethernet/DMX interface with replay unit Application Area: Standalone/Live Interface: Ethernet(LAN), e*net DMX Interface: 2x RJ45 Display: 7 Segment LED IR Receiver: Standard RC5/Traxon IR receiver Memory: SD card (up to 2GB) Live Mode DMX Channels Live: 1024 (Per Device) DMX Universes: 2 Stand Alone Cluster Mode DMX Channels Stand Alone Cluster: 1024 (512x2) Sync interface: e*net (LAN) Show Recall Via IR Remote control: e*com Terminal Technical Power Supply: 5-45vAC/vDC, 4W PoE Compliant Dimensions: 71x24x84mm Weight: 0.15kg Special Features: Robust case with anodized aluminum Find Out More
