Allen and Heath XONE:43C Club and DJ Mixer with integral soundcard

Allen and Heath XONE:43C Club and DJ Mixer with integral soundcard

Allen and Heath XONE:43C Club and DJ Mixer with integral soundcard

Price Each 616.20 Exc VAT or (739.44 Inc VAT at 20%)

.

Ref: JP35032

<Back

Click Here For PDF User Manual

Allen and Heath XONE:43C mixer is supported by leading DJ Software,Serato DJ, and is DVS upgrade ready with the addition of the Serato DJ Club Kit eliminating the need for any external interface. Xone:43C is a 4+1 channel mixer, offering a simple and intuitive layout with sublime analogue audio quality. The mixer is equipped with the legendary Xone filter, 3 band EQ, plus X:FX, giving a single control per channel over the send/return to work with external FX units. The X:FX can also be routed to the Xone filter to add layers of FX and filtering. Xone:43C incorporates a premium quality internal 16 Channel USB Soundcard for integration into digital DJ workflows, plus plug n play connection via X:LINK to Xone:K series controllers for expanded MIDI control. The crossfader has three switchable curve settings for blending or scratching styles and can be easily replaced or upgraded to a custom Innofader for ultimate crossfader performance. With balanced XLR main outputs, independent booth and record outputs, Xone:43C has the quality and versatility to become the centrepiece of the club booth or audiophile personal DJ setup.

Features

16 channel 96kHz 24bit internal soundcard
Serato DJ and DVS Upgrade Ready
X:LINK for plug n play connection to Xone:K series controllers
4 channels with phono/USB/line inputs
VCF Filter system low-pass, high-pass and band-pass filters plus frequency and resonance controls
3-band EQ
External FX loop (Send/Return) system with dry/wet control per channel
Mic input on balanced XLR, with 2-band EQ
Balanced main mix out on XLR
Independent booth out
Record out
3.5mm and 1/4 inch headphone outputs
Touring grade build quality
Super smooth VCA channel faders User changeable crossfader
Innofader compatible
Crossfader curve switch 20dB pro standard headroom
9-segment signal level monitoring

Specifications

Nom / Max Output Levels:
- Main Mix: +4dBu / +27dBu
- Booth: 0dbu / +22dBu
- X:FX Send: 0dBu / +20dBu
- Record Out: 0dBu / +20dBu
Internal Headroom: Channels +20dB
Frequency Response: +/-0.5dB 20Hz - 20kHz
Distortion: <0.05% THD+noise @1kHz
Crosstalik: <-83dB inter-channel
Residual Noise:
- Mix 1: -89dBu
- Booth: -92dBu
- X:FX: -77dBu
- Rec: -92dBu
Channel Meters: Peak Reading 9 LED -20dB to +10dB
Main Meters: Peak Reading 9 LED - 20dB to +10dB
Mic EQ: 2-Band =/-12dB
Channel EQ: 3-Band +6dB / Total kill
Channel Fader: 45mm stereo VCA, <-85dB shutoff
Filters: Stereo VCF, analogue
Digital Architecture Specification
- Analogue/digital conversion: 24 Bit
- Analogue/Digital Line-up: +14dBu = 0dBFS
- USB Soundcard Sampling Frequency Range: 44.1kHx to 96kHz
Consumption: 30W max
Dimensions (WxDxH): 320x370x110
Weight: 5.2kg
