Chauvet Pro COLORdash Batten-Quad 12 RGBA LED Batten, 12x 7W

Chauvet Pro COLORdash Batten-Quad 12 RGBA LED Batten Features

- Built-in auto and custom programs recalled via DMX or Master/Slave
- Metal construction for added durability
- Individual pixel control
- Silent flicker-free operation
- Mount multiple units in stack or end-to-end to maintain pixel pitch

Chauvet Pro COLORdash Batten-Quad 12 RGBA LED Batten Specifications

Optical:
- Light Source: 12 LEDs (quad-color RGBA) 7 W, (500 mA), 50,000 hours life expectancy
- Color Temperature (range): 2,800 to 10,000 K
- Installed Optics: 20°
- Beam Angle: 22°
- Field Angle: 31°
- Illuminance: 539 lux @ 5 m
- PWM Frequency: 600 Hz

Dynamic Effects:
- Dimmer: Electronic
- Shutter/Strobe: Electronic
- Strobe Rate: 0 to 20 Hz
- Standalone Color Mixing: Yes
- Color Temperature Presets: Yes
- Dim Modes: 4
- Built-in Automated Programs: Yes

Connections:
- Power Connection: Edison plug to Neutrik powerCON
- Power Input: Neutrik powerCON
- Power Output: Neutrik powerCON
- Data Connectors: 3- and 5-pin XLR
- Cable Length (signal): 5 ft (1.5 m)

Control:
- Control Protocol: DMX
- DMX Channels: 4, 6, 10, 48 or 52
- Modes/Personalities: 5 personalities (4CH, 6CH, 10CH, 48CH, 52CH)

Electrical:
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power Linking: 16 units @ 230 V; 16 units @ 240 V
- Power and Current: 95 W, 0.743 A @ 230 V, 50 Hz
- Power and Current: 95 W, 0.709 A @ 240 V, 50 Hz

Certification / Qualification:
- CE, MET
- IP Rating: IP20, dry location

Physical:
- Exterior Color: Black
- Dimensions (W x H x D): 1041 x 82 x 164 mm
- Weight: 4.8 kg

Further Product Information Below

Chauvet Pro COLORdash Batten-Quad 12 Manual (PDF)

Chauvet Pro COLORdash Batten-Quad 12 Data Sheet (PDF)

Chauvet Pro COLORdash Batten-Quad 12 Quick Reference Guide (PDF)

Chauvet Pro COLORdash Batten-Quad 12 RGBA LED Batten Supplied With

- COLORdash Batten-Quad 12
- Neutrik powerCON power cord
- 2 Trunnions
