Chauvet DJ EVE B-160Q RGBW Linear LED Batten, 12x 6.5W

Chauvet DJ EVE B-160Q RGBW Linear LED Batten Features

- Full-color linear batten designed for mobile and installation applications
- Up to 8 controllable zones allow for dynamic chase effects
- Pre-set color temperature ranges eliminate the need for manual color blending
- Flicker-free operation suitable for on-camera use
- D-Fi USB compatibility for wireless master/slave or DMX control
- PowerCON-compatible power input/output connections for power linking

Chauvet DJ EVE B-160Q RGBW Linear LED Batten Specifications

- DMX Channels: 3, 4, 11, or 39
- DMX Connectors: 3- and 5-pin XLR
- Light Source: 24 LEDs (quad-colour RGBW) 6.5W, (3.2A) 50,000 hours life expectancy
- Strobe Rate: 0 to 20 Hz
- Beam Angle: 15°
- Field Angle: 30°
- Illuminance: 8,300 lux @ 2 m
- Lumens: 3,909
- Power Linking: 11 units @ 230 V
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power and Current: 102 W, 1.0 A @ 230 V, 50 Hz
- Weight: 4.7 kg
- Size: 1000 x 151 x 194 mm
- Approvals: CE, MET, RoHS
- Beam Angle (w/ filter): 24°
- Field Angle (w/ filter): 52°
- Cable Length: 1.524 m

Further Product Information Below

Chauvet DJ EVE B-160Q Manual (PDF)

Chauvet DJ EVE B-160Q Data Sheet (PDF)

Chauvet DJ EVE B-160Q Quick Reference Guide (PDF)

Chauvet DJ EVE B-160Q RGBW Linear LED Batten Supplied With

- Chauvet EVE B-160Q
- Power cord
- Quick Reference Guide
