Chauvet Pro Ovation 2WL Cool White/Warm White LED Soft Light Fixture

Chauvet Pro Ovation 2WL Cool White/Warm White LED Soft Light Fixture Features

- Effective utility light for use when DMX lighting isn't needed.
- Three selectable color temperatures (3200, 4000, 5600K) providing wide-spectrum, high-CRI lighting
- Soft, flood lighting minimizes shadows
- Use with direct line voltage and can be dimmed via off-the-shelf phase cut or triac dimmers

Simple Non-DMX Operation:

Integrates seamlessly into any system using direct line voltage, eliminating the need for DMX control in utility lighting applications

Choose between three high-CRI color temperatures to perfectly match ambient lighting for broadcast, theatre, or architectural environments

A wide, soft flood beam minimizes shadows and provides smooth, even coverage for general area illumination or houselighting

Achieve smooth dimming using conventional off-the-shelf phase-cut or triac dimmers, allowing for simple and cost-effective system integration

Chauvet Pro Ovation 2WL Cool White/Warm White LED Soft Light Fixture Specifications

Optical:
- Light Source: 960 LEDs (CW, WW)
- Colour Temperature (3200k): 3217 K
- Colour Temperature (4000k): 3960 K
- Colour Temperature (5600k): 5584 K
- CRI (3200K): 95.3
- CRI (4000K): 95.2
- CRI (5600K): 94.0
- Beam Angle: 107.4°
- Field Angle: 158.7°
- Lumens (3200k): 10,564
- Lumens (4000k): 10,954
- Lumens (5600k): 11,328
- Illuminance 3200k): 158 lux @ 5 m
- Illuminance (4000k): 164 lux @ 5 m
- Illuminance (5600k): 169 lux @ 5 m

Dynamic Effects:
- Dimmer: External Dimmer (phase cut or triac compatible)
- On-board Colour Temperature Selection

Connections:
- Power Connection: Edison (local) plug to Seetronic Powerkon IP65
- Power Input: Seetronic Powerkon IP65
- Power Output: Seetronic Powerkon IP65
- Cable Length (power): 5 ft (1.5 m)

Electrical:
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power Linking: 23 units @ 230 V
- Power and Current: 98 W, 0.51 A @ 230 V, 50 Hz
- Breaker Size: T2.5 A, 350 V

Certifications / Qualifications:
- CE, MET, FCC, RoHs
- IP Rating: IP20, dry location
- Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

Construction / Physical:
- Dimensions: 445 x 281 x 139 mm
- Weight: 4.6 kg
- Exterior Colour: Black
- Housing Material: Aluminium alloy
- Accessory Holder/Gel Frame Size: 365.125 x 216 x 3.175 mm

Further Product Information Below

Chauvet Pro Ovation 2WL Data Sheet (PDF)

Chauvet Pro Ovation 2WL Quick Reference Guide (PDF)

Chauvet Pro Ovation 2WL Cool White/Warm White LED Soft Light Fixture Supplied With

- Chauvet Ovation 2WL
- Seetronic Powerkon power cable
- Omega Bracket with mounting hardware
