Chauvet Pro COLORado Solo Pod E RGBL LED Spot - IP65

Chauvet Pro COLORado Solo Pod E RGBL LED Spot Features

- High-performance RGBL LED wash with variable electronic frost for touring, rental, and production -indoors or out
- High-power with smooth and even color mixing
- Variable electronic frost for beam/edge softness control
- All environment operation with IP-rated power and DMX connections
- Easy mounting using traditional clamps, quick connecting omega bracket, or split yoke floor stand
- Instant Beam Shaping: Integrated electronic frost instantly shifts the beam from a tight spot to a wide wash for dynamic, on-the-fly adjustments without mechanical parts
- Superior Color Performance: A high-power RGBL LED engine delivers fully homogenized output with smooth, even color mixing and a wide range of vibrant, high-quality hues.
- All-Weather Reliability: Built for any environment, its IP65-rated housing and connections ensure dependable performance for touring, rental, and production, both indoors and out.
- Flexible Rigging Options: Mount fixtures quickly and securely using the included omega bracket, traditional clamps, or an optional split yoke for fast setups in any orientation.
- Flawless On-Camera Operation: Achieve perfect on-camera results with 16-bit dimming and selectable PWM frequencies that eliminate flicker for broadcast, IMAG, and streaming applications

Chauvet Pro COLORado Solo Pod E RGBL LED Spot Specifications

Optical:
- Light Source: 12 LEDs (quad-colour RGBL) 180W, (1.3A), 50,000 hours life expectancy.
- Colour Temperature (range): 2800 to 8000 K
- Colour Temperature (at full): 11,550 K
- CRI @ 3200 K: 83.8
- Beam Angle: 17.1°
- Beam Angle (E-Frost): 54.7°
- Field Angle: 30.9°
- Field Angle (E-Frost): 128.9°
- Lumens: 8160
- Lumens (E-Frost): 7030 Illuminance: 2673 lux @ 5 m
- Illuminance: 2673 lux @ 5 m
- Illuminance (E-Frost): 220 lux @ 5 m
- Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz

Dynamic Effects:
- Dimmer: Electronic
- Shutter/Strobe: Electronic
- Frost: Electronic
- Strobe Rate: 0 to 25Hz
- Standalone Colour Mixing: Yes
- Colour Temperature Presets: Yes
- Dim Modes: 4
- Dim Curves: 4
- Built-in Automated Programs: Yes

Connections:
- Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
- Power Input: Seetronic Powerkon IP65
- Power Output: Seetronic Powerkon IP65
- Data Connectors: 5-pin IP65 XLR,
- Cable Length (power): 5 ft (1.5 m)
- Software Connection: USB

Control:
- Control Protocol: DMX, RDM
- DMX Channels: 1ch, 5ch1, 5ch2, 7ch, 11ch, 12ch, 13ch, 16ch or HSV
- Modes/Personalities: 9 personalities (1ch, 5ch1, 5ch2, 7ch, 11ch, 12ch, 13ch, 16ch, HSV)

Electrical:
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power Linking: 7 units @ 120 V; 12 units @ 208 V; 13 units @ 230 V
- Power and Current: 189 W, 0.86 A @ 230 V, 50 Hz

Certifications / Qualifications:
- CE, MET, FCC,
- IP Rating: IP65, outdoor/wet, with pressure equalizing M12 GORE valve
- Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)

Construction / Physical:
- Dimensions: 283 x 208 x 405.5 mm
- Weight: 7.2 kg
- Exterior Colour: Black
- Housing Material: Aluminium

Further Product Information Below

Chauvet Pro COLORado Solo Pod E Manual (PDF)

Chauvet Pro COLORado Solo Pod E Quick Reference Guide (PDF)

Chauvet Pro COLORado Solo Pod E DMX Chart(PDF)

Chauvet Pro COLORado Solo Pod E RGBL LED Spot Supplied With

- Chauvet COLORado Solo Pod
- Powerkon IP65 power cord
- Gel frame
