Cloud CS-SUB8W Surface Mount Subwoofer - White

Cloud CS-SUB8W Surface Mount Subwoofer - White

Cloud CS-SUB8W Surface Mount Subwoofer - White

Price Each 174.97 Exc VAT or (209.96 Inc VAT at 20%)

For Install and Dealer Volume prices please contact us.

Need to Price Match it ? Click Here to see what we can do.

Ref: JP33122

<Back

Click Here For PDF User Manual

The Cloud CS-SUB8 is an 8 inch passive subwoofer featuring powerful bass response in a small package. Using a premium woofer and first order crossover network, the CS-SUB8 adds punch and low end reinforcement to Clouds line of full range speakers. The 8.0 inch woofer incorporates a large magnet structure, treated paper cone, and long throw butyl rubber surround for lasting, low distortion performance. The included 100 W transformer provides plenty of power for background to foreground music applications. The CS-SUB8 incorporates several features that make it a premium, versatile subwoofer. The low profile cabinet is easy to hide in any installation, but the architectural aesthetic makes it desirable to show. The CS-SUB8 ships with rubber feet installed for floor or shelf mounting, and includes a versatile surface mount bracket that can securely mount the speaker in either the vertical or horizontal orientation. It can also be flown via the threaded inserts on the side or bottom. The CS-SUB8 pairs well with the CS-S3 and CS-C3 to make a complete, premium business music system.

Features

Premium driver and electronics for exceptional sound quality and intelligibility
Integrated high power transformer
Striking architectural aesthetic
Versatile mounting using included rubber feet, or included surface mount bracket
Optional flying using forged eye bolts and cables (sold separately)

Specifications

Description 8 passive surface or shelf mount subwoofer
Response (f3) 74 Hz -200 Hz
Response (f10) 58 Hz -500 Hz
Impedance 4 ohm
Sensitivity (2.83 V/1 m) 90 dB
Sensitivity (1 W/1 m) 87 dB
Power handling 100 W
Maximum SPL 107 dB
Transformer taps 100, 50, 25,13, 7 W
Tweeter n/a Woofer 8 inch treated paper with rubber surround
Input 4 pin Euroblock
Included accessories Input cover plate (installed), male Euroblock, rubber feet, surface mount bracket
Optional accessories M6 forged eyebolts for hanging
Available colours Black, white
Packaging 1 per box, cardboard inner packaging, single instruction sheet
Dimensions 419.4mm x 219.4mm x 271.5mm (inc feet)
Net weight/Gross weight 5.0 kg (11 lb) / 7.0 kg (15.43 lb)
Conformance UL1480 / 2043 planned, RoHS, CE approved
