Ecler BOB-22 Dante Interface with 2 Inputs & 2 Outputs

Ecler BOB-22 Dante Interface with 2 Inputs & 2 Outputs Features

- Ethernet interface
- Euroblock connectors for analogue audio inputs and outputs
- 2 Analogue MIC/LINE audio inputs reception
- 2 Analogue LINE level audio outputs
- 2x2 Digital audio -transmission and reception -channels in Dante/AES67 format
- PoE power supply ready
- Phantom power (+48VDC by internal jumper activation)
- Input sensitivity (adjustable from -50dBV to +0dBV)
- Compact format
- Frontal support Half rack accessory included

Ecler BOB-22 Dante Interface with 2 Inputs & 2 Outputs Specifications

Audio Converters:
- Sampling rate: 48kHz
- Resolution: 24 bit
- Latency:
  - ADC 0.81 ms
  - DAC 0.56 ms
  - Total 1.37 ms
- Frequency response: 0 - 20kHz
- Dynamic range: ADC:110dB, DAC:115dB

Analogue Audio Input Ports:
- Number of input ports: 2, MIC/LINE level
- Connection type: Euroblock, 3-pin, balanced
- Input sensitivity: -50dBV to +0dBV
- Input impedance: > 4 kΩ
- Max input level: +18dBV = +20dBu
- THD + Noise @ 1kHz:
  - Line: 0dBV input (line) <0.005%
  - Mic: -40dBV input (mic.) <0.40%
- CMRR: 56dB typ.
- Phantom power: +48VDC, Internal jumper activation

Analogue Audio Output Ports:
- Number of output ports: 2, LINE level
- Connection type: Euroblock, 3-pin, balanced
- Max output level: +18dBV = +20dBu
- Output impedance: 316 Ω
- Crosstalk: better than 95dB

Audio Over Ip:
- Protocols: Dante / AES67 (2/2 flows)
- Number of digital input ports: 2
- Number of digital output ports: 2
- Interfaces: 1x RJ-45

Connectivity:
- Ethernet: 1, RJ-45 connector 10 /100Mb, 1GB Auto X-Over
- Programing and control: Dante Controller

Electrical:
- Power supply: 24VDC External PSU (sold separately)
- Secondary power supply: PoE: class 0 802.3af Poe PD compliant
- AC mains requirement: 90-265VAC @ 50-60Hz (External PSU: 24VDC)
- Power consumption: 14 VA / 8W
- Ventilation: Passive

Physical:
- Operating temperature: Min: -10°C ; 14°F Max: 40°C ; 104°F
- Operating humidity: <85% HR
- Storage temperature: Min: -10°C ; 14°F Max: 40°C ; 104°F
- Storage humidity: <90% HR
- Installation options: Desktop, 19-inch racks (1RU)
- Dimensions (WxHxD): 266.1 x 44 x 156.2 mm
- Weight: 1.1 Kg

Further Product Information Below

Ecler Bob 22 Manual (PDF)

Ecler Bob 22 Data Sheet (PDF)

Ecler Bob 22 Technical Drawing (PDF)

Ecler BOB-22 Dante Interface with 2 Inputs & 2 Outputs Supplied With

- 1x Ecler CBOB22
- 4x Euroblock 3-pin connectors
- 4x Rubber feet
- 1x Frontal Support Half-Rack accessory
- 4x Washer
