Ecler VEO-SWC44 Wireless BYOD Presentation Switcher

Ecler VEO-SWC44 Features

- USB 3.0 ports for wireless connection between a laptop and room USB devices like camera and mic for an easy video conference
- Wireless input up to Full HD video resolution and a HDMI 4K / UHD video output
- Analogue audio extraction on stereo unbalanced 3,5mm jack connector
- Support for native wireless mirroring protocols like Airplay and Miracast for a flawless presentation
- Plug-n-play by optional wireless transmitters HDMI VEO-SWC44TH or USB Type-C VEO-SWC44TU as well as Windows and macOS apps for wireless connection with a laptop or PC
- RS-232 and IP control as well as WebGUI management
- Extra security layer for an encrypted wireless transmission
- Support for up to 4 simultaneous split screen view presentation as well as up to 16 participants on hold
- Customizable background image or logo for the welcome screen page
- Support wireless touchback for interactive screen as well as whiteboard and live annotation tool
- Support for PoE
- Local 12V DC power supply

Ecler VEO-SWC44 Specifications

Video Perfomances:
- Video Input Connectors : USB 3.0, USB-C, USB 2.0 (UVC)
- Video Output Connectors: HDMI Type A Female, 1.4, 10.2 Gbps
- Video Input Resolutions : 1080p @ 60Hz
- Video Output Resolutions: 3840x2160@60Hz,3840x2160@30Hz, 1920x1080@60Hz, 1280x720@60Hz
- HDCP: 2.2
- HDMI Distance: 10m with Ecler VEO Cables

Audio Performances:
- Audio Output Connectors: Jack 3.5mm
- Audio Formats: PCM 2.0
- Audio De-Embedding: Yes

Device Control:
- Control Connectors: USB Type A, Euroblock, RJ-45
- Control Protocols: Web, Telnet, RS-232
- Control Buttons: 1x Power ON button
- EDID Management: Software
- Status Indicators: Input LED Multicolour

Network:
- Network Connectors: 2x RJ-45 (LAN port 1 is 100Mbps and LAN port 2 is 1Gbps), WiFi (Wireless transmission protocol is WIFI IEEE 802.11 a/g/n/ac. Compatible with 2.4GHz and 5GHz frequency bands)
- Average Streaming Bitrate: Up to 1200Mbps
- Transmission Distance: 100m via Ethernet Network

Electrical:
- Power supply: PoE (IEEE802.3af.) or External Power supply
- AC mains connector: 100-240VAC 50-60Hz with EU, UK, US, AU blades
- DC mains connector: 12VDC-3A with coaxial DC connector
- Power consumption: 10W

Physical:
- Operating temperature: Min: -20°C; -4°F Max: 60°C; 140°F
- Operating humidity: <90% HR
- Installation options: Desktop
- Chassis material: Metal
- Finished colour: Black
- Dimensions (W x H x D):
  - Without antenna: 220 x 32 x 120 mm
  - Including antenna: 220 x 145 x 120mm
- Weight: 1 Kg

Further Product Information Below

Ecler VEOSWC44 Driver Manual (PDF)

Ecler VEOSWC44 Data Sheet (PDF)

Ecler VEOSWC44 Technical Drawing (PDF)

Ecler VEO-SWC44 Supplied With

- 1x Ecler CVEOSWC44
- 1x 3-pin Euroblock connector
- 3x antennas
- 1x 12V PSU
