FBT AX 1200 2 Ch. Power Amp - 2x600Wrms (4ohm) - 1200Wrms (8ohm bridge)

FBT AX 1200 2 Ch. Power Amp - 2x600Wrms (4ohm) - 1200Wrms (8ohm bridge)

FBT AX 1200 2 Ch. Power Amp - 2x600Wrms (4ohm) - 1200Wrms (8ohm bridge)

Price Each 371.36 Exc VAT or (445.63 Inc VAT at 20%)

Contact us for quantity price breaks 01271 862221

Ref: JP54329

<Back

Click Here For PDF User Manual

FBT AX1200 2 Ch. Power Amp - 2x600Wrms (4ohm) - 1200Wrms (8ohm bridge) Tour tough built, sleek design, impressive specs, excellent cost per watt performance, efficient under any application. With these credentials, FBT proudly presents the new AX series of power amplifiers, the perfect power mates for sound reinforcement speaker systems. The AX series consists in four 2HU rack mount models, from 800 to 3000 watts, all designed with sophisticated power amp circuits for improved quality, stability and reliability, all equipped with Stereo-Parallel-Bridge operation mode, dB sensitivity switch (26-29-32dB), limiter, ground lift, XLR/Jack inputs (plus extra RCA input on AX 800), Speakon/Binding posts outputs.

Suitable applications: Amplification for live sound reinforcement speaker systems in clubs, discos, piano bar, conference halls, houses of worship, sports arenas, schools, theatres, mobile D.J. use, recording studio monitors, foreground music reproduction, etc.

Features & Specifications

Both channel driven 8 ohm 1% THD Continuous/impulsive: 340/350W
Both channel driven 4 ohm 1% THD Continuous/impulsive: 460/600W
Bridge 8ohm 1% THD: 920/1200W
Input impedance: 20K balanced
Signal to noise ratio S/N: >100dB
Total harmonic dist. (1kHz-4ohm): < 0.03%
Frequency response: 20Hz-40Khz -6dB
Damping Factor: > 400
Class: H - 2 step
Maximum power consuption: 1300VA
Power supply voltage: 120 or 230 Vac 50/60Hz
Protections: Short circuit / thermal
Cooling: in: XLR/Jack out: Speakon/Binding post

Net Dimension (WxHxD): 482 x 88 x 290mm
