JBL AWC82 - Grey - All-Weather Compact 2-Way Coaxial Loudspeaker with 8" LF

JBL AWC82 - Grey - All-Weather Compact 2-Way Coaxial Loudspeaker with 8

JBL AWC82 - Grey - All-Weather Compact 2-Way Coaxial Loudspeaker with 8" LF

Price Each 485.44 Exc VAT or (582.53 Inc VAT at 20%)

.

Ref: JP3581

<Back

Click Here For PDF User Manual

The JBL AWC82 is a compact, coaxial-driver, 2-way, highly weather-resistant full-range loudspeaker system which is ideal for speech and music-fill in a wide variety of applications, including sports facilities, racetracks, stadiums, fairgrounds, rodeos, skating rinks, themed entertainment venues, cruise ships, water parks, outdoor background music/paging systems, swimming pools, and a wide variety of other outdoor or indoor venue types.

Features

  • Highly weather-resistant IP56 rating
  • Consistent 120 x 120 broadband pattern control
  • Components: 200 mm (8 in) woofer with Kevlar-reinforced cone and 50 mm (2 in) voice coil, 25 mm (1 in) exit compression driver with unique patented design and high temperature polymer diaphragm
  • Extraordinary clarity for speech, with extended frequency response for music
  • Advanced high-slope crossover network for constant coverage and smooth, natural midrange
  • 250 Watt power handling (average continuous pink noise) with high sensitivity provides high SPL capability
  • High-power passive crossover network
  • Overload protection 80 Hz - 20 kHz frequency response
  • 200 Watt 70V/100V multi-tap (built-in transformer) or Direct 8 Ohmm low-impedance

Specifications

High Frequency Driver 25 mm (1 in) diaphragm and voice coil diameter, high temperature polymer diaphragm, patented design, fluid-cooling.
HF Driver Protection Minimum audibility SonicGuardT HF overload protection
Enclosure ABS with Glass enclosure, heavily braced
Attachment Two M10 (fine-thread) points for included U-bracket. M6 secondary safety attachment point on back panel.
Grille Corrosion-resistant zinc-rich extra-thick powder coated steel grille, 3-layer assembly with foam and woven poly mesh backing.
Input Connection CE-compliant covered barrier strip terminals. Barrier terminals accept up to 9 mm outside 4 mm inside open-lug (#6, #8 or #10) plus bare wire up to 2.5 mm2 (12 AWG) wire or spade lugs. Terminal compartment cover equipped with gland nut that forms water-tight seal with round-jacketed cables with outside diameters between 4.0 mm (0.16") and 9.0 mm (0.36")
Environmental IP56 per IEC529, with a minimum 5 downward aiming angle. Exceeds Mil Spec 810 for humidity, salt spray, temperature & UV, and ASTM G85 for salt spray (168 hrs).
Dimensions 300 x 300 x305 mm (11.8 x 11.8 x 12.0), cabinet 331 mm (13.0 in) including gland nut 359 mm (14.2 in) including bracket extending to back
Colors Available in gray (similar to Pantone 420C) and black (-BK)
Net Weight 9.8 kg (21.5 lb), 11.6 kg (25.5 lb) with U-bracket
Shipping Weight 14.1 kg (31.0 lb)
Included Accessories U-bracket, matches loudspeaker color (gray or black), zinc-rich extrathick powder coated, steel.
Frequency Range (-10 dB) 80 Hz - 20 kHz
Frequency Response (3 dB) 100 Hz - 20 kHz
Coverage Pattern 120 x 120
Directivity Factor (Q) 8.1 (1 k - 16 kHz)
Directivity Index (DI) 8.4 dB (1 k - 16 kHz)
Long-Term System Power Rating (IEC) 250 W 2 hrs. 200 W 100 hrs
Sensitivity (2.83V @ 1m) 94 dB (Ave. 100 Hz - 20 kHz)
Maximum SPL Direct 8 Ohm: 118 dB (peaks of 124 dB) 200 W Tap: 117 dB
Crossover Network 1.8 kHz, 3rd order (18 dB/oct) high-pass plus conjugate to HF, 2nd order low-pass to LF
Nominal Impedance 8 ohms
Transformer Taps 70V: 200W, 100W, 50W, 25W100V: 200W, 100W, 50W
Low Frequency Driver Kevlar-reinforced cone with weather treatment, 50 mm (2 in) voice coil.
