Lucenti Blackwave BW50 Pixel Bar, IP66

Name: Lucenti Blackwave BW50 Pixel Bar, IP66
Brand: Lucenti
Price: 170.03 GBP
Availability: InStock

Price Each £141.69 (£170.03 Including VAT at 20%)

REF: JP105482

Quantity:

Lucenti Blackwave BW50 Pixel Bar, IP66

The Lucenti Blackwave BW50 Pixel Bar is a pixel mappable bar controllable by Art-Net or sACN. They feature a wide 120° viewing angle and feature a black stealth front lens. Clear, frosted, rounded or square lenses are also available to further expand the versatility of these fixtures. The system is configured by using a single controller for up to 128 bars arranged in groups of eight. The strips are easy to link via the Blackwave 4-Pin cables.

Click Here for Printer Friendly Version

Lucenti Blackwave BW50 Pixel Bar Features

- 25 quad-colour SMD 5050 LEDs (RGBW)
- Viewing angle: 120°
- Pixels: 25
- Pixel pitch: 15mm
- Blackwave Pixel Bar requires the PixlDrive1/PixlDrive8Pro Driver for operation
- Design allows for multiple rigging applications
- Pixlbus 4-Pin input/output (power/data)
- Convection cooled
- IP rating: IP66

Lucenti Blackwave BW50 Pixel Bar Specifications

- Power consumption: 7W
- Power supply: 24V
- Dimensions (H x W x D): 20 x 500 x 39 mm
- Weight: 0.5 kg

Further Product Information Below

Lucenti Blackwave BW50 Pixel Bar Data Sheet (PDF)

Lucenti Blackwave System Specification (PDF)

Lucenti Blackwave Cabling Considerations (PDF)

Lucenti Blackwave BW50 Pixel Bar Supplied With

- 1x I-Frame Coupler
- 1x Mounting Block M6 included
