Lynx LUKA-226 Loudspeaker Processor, 2 In / 6 Out

Lynx LUKA-226 Loudspeaker Processor Features

- 2 analogue inputs + AES3 2-channel digital input
- 6 analogue outputs
- 64-bit DSP internal resolution
- 32-bit AD/DA converters, max input +24 dBu
- Dynamic range: 121 dB (in) / 120 dB (out)
- FIR processing up to 1000 taps per output
- User EQ: High-Pass + 10 Parametric
- Mode EQ: High-Pass/Low-Pass + 10 Parametric
- Output EQ: High-Pass/Low-Pass + 12 Parametric + FIR custom
- Full PEQ filter set including AllPass
- RMS limiters + Peak limiters per output
- Input matrix with Simple / Basic / Advanced routing
- Backup-priority input selection
- Delay up to 206 ms (≈70 m) on ins/outs
- 999 presets: User, Snapshot & Speaker
- USB & Ethernet remote control
- 320 x 170 IPS colour display, joystick + dedicated mute/edit butt

Lynx LUKA-226 Loudspeaker Processor Specifications

- Inputs: 2x analogue balanced XLR, AES3 (2-channel)
- Input impedance: 10kΩ balanced
- Outputs: 6x analogue balanced XLR
- Output impedance: 200Ω balanced
- Max output level: +24dBu
- Audio frequency range: 10Hz - 24kHz
- Latency: 1.17ms
- Power: 85-240V AC, 20W
- Dimensions: 483 x 45 x 200mm
- Weight: 3kg
