Netgear MSM4214X M4250-12M2XF Managed Switch

Name: Netgear MSM4214X M4250-12M2XF Managed Switch
Brand: Netgear
Price: 1115.88 GBP
Availability: InStock

Price Each £929.90 (£1,115.88 Including VAT at 20%)

REF: JP113687

Quantity:

Netgear MSM4214X M4250-12M2XF Managed Switch

The Netgear MSM4214X M4250-12M2XF Managed Switch is a fully managed AV switch engineered for professional audio-visual installations. Featuring 12 independent 1G/2.5G RJ45 ports and 2 10G SFP+ uplinks, it supports advanced multicast, AVB, and PTP time synchronisation protocols. Designed for low-latency video and audio signal routing, it integrates seamlessly with leading AV over IP ecosystems including Dante, NDI, AES67, and more. With a fanless design and AV-centric configuration interface, the M4250-12M2XF ensures silent operation, intuitive management, and reliable performance for demanding AV environments.

Click Here for Printer Friendly Version

Netgear MSM4214X M4250-12M2XF Managed Switch Features

- 12x 1G/2.5G RJ45 ports for high-speed AV connectivity
- 2x 10G SFP+ uplink ports for fast backbone integration
- Fanless design for silent operation in noise-sensitive environments
- AVB (Audio Video Bridging) and PTP (Precision Time Protocol) support
- Pre-configured AV profiles for Dante, AES67, NDI, Q-SYS, and more
- Audio-Video web-based user interface (AV UI) for simplified setup
- Compatible with NETGEAR Engage Controller and Insight platforms
- Compact 1U form factor with desktop and rack-mount options
- Robust multicast, VLAN, QoS, and IGMP support
- Designed for professional AV installations, studios, and venues

Netgear MSM4214X M4250-12M2XF Managed Switch Specifications

- Model: MSM4214X
- Ports: 12x 1G/2.5G RJ45, 2 x 10G SFP+
- Management: Web UI (AV UI & main UI), CLI, SNMP, Engage Controller, Insight
- Switching Capacity: 88Gbps
- MAC Address Table: 32K entries
- Latency: <3μs for 64-byte frames
- Fan: Fanless design
- Mounting: Desktop, rackmount, or under-table
- Dimensions: 440 x 204 x 43.2mm (W x D x H)
- Weight: 2.46kg
- Power Supply: Internal, 100-240V AC
- Operating Temperature: 0°C to 45°C

Further Product Information Below

Netgear M4250-12M2XF Manual (PDF)

Netgear M4250-12M2XF Data Sheet (PDF)
