NovaStar ET4S-G (P2) Media Server

Name: NovaStar ET4S-G (P2) Media Server
Brand: NovaStar
Price: 5568.7 GBP
Availability: InStock

Price Each £4,640.58 (£5,568.70 Including VAT at 20%)

REF: JP112552

Quantity:

NovaStar ET4S-G (P2) Media Server

The NovaStar ET4S-G (P2) Media Server is designed for multimedia exhibition halls, stage performances and other creative fixed installation applications. It is equipped with the MPG2200 graphics card and supports up to 8K x 4K output. The ET4S-G (P2) supports up to four DP 1.4 mosaic outputs to easily drive creative mosaic displays on irregular screens. Splitting, merging and rotating are supported, and each output can be split into up to 64 partitions, enabling quick mapping settings and ultra-wide screen configurations. Up to 12 layers and 1 audio stream can be played back simultaneously.

The included Kompass FX3 software ensures seamless, ultra-clear and smooth video playback with support for common video formats including H.264, H.265, MPEG-4/2, WMV and VP9. Six USB 3.0 ports provide fast external storage and mouse/keyboard connectivity. The software offers user-friendly media library management and supports PowerPoint files, NDI sources, website sources, streaming media and text sources. Its intuitive and user-friendly interface makes it easy to control content playback. NovaStar's Visual Intelligent Control Platform (VICP) allows remote playback control as well.

Click Here for Printer Friendly Version

NovaStar ET4S-G (P2) Media Server Features

- Max. output resolution: 4x 5120 x 2880 @60 Hz
- Mosaic output support for all outputs
- Each output supports up to 8192 pixels width or height
- Kompas FX3 software license included (dongle)
- NDI support

NovaStar ET4S-G (P2) Media Server Specifications

Inputs:
- Mono Inputs: 1
- Mono Input Connector: TS unbalanced 3.5 mm
- Stereo Inputs: 1
- Stereo Input Connector: TRS balanced 3.5 mm

Outputs:
- DP1.4 (out): 4
- HDMI (for Control): 1
- USB 3.0: 6
- Stereo Outputs: 4
- Stereo Outputs (type): XLR 3P / TRS balanced 3.5mm

Control and Programming:
- Output Resolution: 5120 x 2880
- NDI Supported: Yes

Software Specifications:
- Supported Layers: 12

Playback:
- Processor: 12th Generation Intel Core

Server Specifications:
- AV Software Included: Yes
- AV Software Package: Kompas FX3
- Memory Type: DDR5
- Memory Size: 32 GB
- Storage 1 Type: SSD
- Storage 1 Size: 250 GB
- Storage 2 Type: SSD
- Storage 2 Size: 1000 GB
- Graphics Card Type: MPG2200
- Video RAM Type: GDDR5X
- Video RAM Size: 5 GB
- Maximum Resolution Width: 16384 px
- Maximum Resolution Height: 16384 px

Electrical Specifications and Connections:
- Power Supply: 100-240 V AC 50/60 Hz
- Power Consumption: 500 W
- Power Connector In: IEC
- Data Connector: RJ45 In/Out, USB

Mechanical Specifications:
- Dimensions (W x H x D):
- With handles: 483 x 184 x 642 mm
- Without handles: 440 x 177 x 598 mm
- Weight: 17 kg (37.479 lb)
- Rack Units: 4 U
- IP Rating: IP20 (indoor use only)
- Colour: Black

Product Properties:
- Cooling: Active

Extra Features:
- GenLock: In & Out

Thermal Specifications:
- Maximum Ambient Temperature: 40 °C (104 °F)
- Operating Humidity: 0-80 %rH

Further Product Information Below

NovaStar ET4S-G (P2) Manual (PDF)

Please Note: This Item is to Order from NovaStar and is NON CANCELLABLE. If you require a lead time please contact us first before you place your order.

NovaStar ET4S-G (P2) Media Server Supplied With

- DP-DP cable
- HDMI-HDMI cable
- IEC cable
- Keyboard (USB)
- Mouse (USB)
