NovaStar H-Series Input Card with 2x HDMI 2.0 or 2x DP 1.2

Name: NovaStar H-Series Input Card with 2x HDMI 2.0 or 2x DP 1.2
Brand: NovaStar
Price: 2008.38 GBP
Availability: InStock

Price Each £1,673.65 (£2,008.38 Including VAT at 20%)

REF: JP112535

Quantity:

NovaStar H-Series Input Card with 2x HDMI 2.0 or 2x DP 1.2

The NovaStar H-Series Input Card with 2x HDMI 2.0 or 2x DP 1.2 is an input card for the H Series H2/H5/H9/H15 Video Wall Splicers. It is HDCP 2.2 compliant. It accepts two HDMI 2.0 signals, one HDMI 2.0 and one DP 1.2 signal, OR two DP 1.2 signals (not all four inputs at the same time). The HDMI 2.0 inputs are backwards compatible with HDMI 1.4 and 1.3 and support resolutions of up to 4092x2263 @60 Hz or 2188x4095 @60 Hz. The DP 1.2 inputs are backwards compatible with DP 1.1 and support resolutions of up to 8192x1152 @60 Hz or 2188x4095 @60 Hz. Four status LEDs indicate if the input signal is valid.

Click Here for Printer Friendly Version

NovaStar H-Series Input Card with 2x HDMI 2.0 or 2x DP 1.2 Features

- Supports HDMI 2.0 and DP 1.2
- HDCP 2.2 compliant
- Four status LEDs

NovaStar H-Series Input Card with 2x HDMI 2.0 or 2x DP 1.2 Specifications

Inputs:
- DP 1.2: 2
- HDMI 2.0: 2
- Input Slots: 1

Control and Programming:
- Maximum Input Resolution: 3840 x 2160, 4096 x 2160, 8192 x 1080, Width and Height can be defined by users

Mechanical Specifications:
- Weight: 0.55 kg (1.213 lb)
- IP Rating: IP20 (indoor use only)
- Colour: Black

Further Product Information Below

NovaStar H2 Manual (PDF)

NovaStar H5 Manual (PDF)

NovaStar H9 Manual (PDF)

Please Note: This Item is to Order from NovaStar and is NON CANCELLABLE. If you require a lead time please contact us first before you place your order.
