NovaStar MX-Series Input Card with 2x ST2110 (25G)

Name: NovaStar MX-Series Input Card with 2x ST2110 (25G)
Brand: NovaStar
Price: 5075.03 GBP
Availability: InStock

Price Each £4,229.19 (£5,075.03 Including VAT at 20%)

REF: JP112547

Quantity:

NovaStar MX-Series Input Card with 2x ST2110 (25G)

The NovaStar MX-Series Input Card with 2x ST2110 (25G) is an input card for the Novastar MX Series main frames. It accepts two video signals with a resolution of up to 4096x2160 @ 60 Hz via two 25G SFP28 interfaces, enabling 'Video over IP' over distances of up to 10 km. This allows the LED display controller to be integrated into standard IP systems, providing flexible configuration options such as switching between input sources at broadcast control or production centres.

Please Note: Single or Multi mode 25G SFP modules are not included and should be purchased separately to meet your specific network requirements.

Click Here for Printer Friendly Version

NovaStar MX-Series Input Card with 2x ST2110 (25G) Features

- Supports 2x SMPTE 2110
- Maximum input resolution 4096x2160 @ 60 Hz per input
- Two primary and two backup ports with status LEDs
- Supports Single Mode and Multi Mode fibre transmission

NovaStar MX-Series Input Card with 2x ST2110 (25G) Specifications

Inputs:
- Input Slots: 1

Optical:
- SFP Slot Type: 25G
- SFP Slot Quantity: 4

Control and Programming:
- Maximum Input Resolution: 4096 x 2160

Mechanical Specifications:
- Weight: 0.5 kg
- IP Rating: IP20 (indoor use only)
- Colour: Black

Further Product Information Below

NovaStar MX2000 Pro Manual (PDF)

NovaStar MX6000 Pro Manual (PDF)

Please Note: This Item is to Order from NovaStar and is NON CANCELLABLE. If you require a lead time please contact us first before you place your order.
