NovaStar MX-Series Input Card with 4x 12G-SDI

Name: NovaStar MX-Series Input Card with 4x 12G-SDI
Brand: NovaStar
Price: 2905.16 GBP
Availability: InStock

Price Each £2,420.97 (£2,905.16 Including VAT at 20%)

REF: JP112548

Quantity:

NovaStar MX-Series Input Card with 4x 12G-SDI

The NovaStar MX-Series Input Card with 4x 12G-SDI is an input card for the Novastar MX Series main frames. It accepts four inputs, each with resolutions up to 4096 x 2160 @ 60 Hz. It supports ST-2082 (12G), ST-2081 (6G), ST-424 (3G) and ST-292 (HD) standard video inputs, as well as 3G-Level A/Level B (DS mode). HDR10 and HLG are also supported and it complies with SMPTE ST 2084 and 2086 standards. Four status LEDs indicate whether the input signals are valid.

Click Here for Printer Friendly Version

NovaStar MX-Series Input Card with 4x 12G-SDI Features

- Supports 12G-SDI, 6G-SDI, 3G-SDI and HD-SDI
- Supports HDR10 and HLG
- Supports interlaced signals
- Four status LEDs

NovaStar MX-Series Input Card with 4x 12G-SDI Specifications

Inputs:
- 12G-SDI: 4
- Input Slots: 1

Control and Programming:
- Maximum Input Resolution: 4096 x 2160

Mechanical Specifications:
- Weight: 0.8 kg
- IP Rating: IP20 (indoor use only)
- Colour: Black

Further Product Information Below

NovaStar MX2000 Pro Manual (PDF)

NovaStar MX6000 Pro Manual (PDF)

Please Note: This Item is to Order from NovaStar and is NON CANCELLABLE. If you require a lead time please contact us first before you place your order.
