NovaStar MX-Series Output Card with 1x 40G Fibre

Name: NovaStar MX-Series Output Card with 1x 40G Fibre
Brand: NovaStar
Price: 3964.94 GBP
Availability: InStock

Price Each £3,304.12 (£3,964.94 Including VAT at 20%)

REF: JP112549

Quantity:

NovaStar MX-Series Output Card with 1x 40G Fibre

The NovaStar MX-Series Output Card with 1x 40G Fibre is a fibre sending card for the Novastar MX 2000 and MX 6000 main frames. It is compatible with the 5G platform (no backward compatibility). It has a 40G optical output port that supports single and multi-mode fibre modules and a maximum transmission distance of 10 km. It offers 8 5G Ethernet ports with a maximum total loading capacity of more than 17 million pixels.

To use the fibre optic output signal with LED panels, a fibre converter such as the CVT-5G-S or the CVT8-5G-M is required to convert the signal to suitable network cable signals. Please note that the required 40G SFP module is not included. However, each CVT8-5G fibre converter is supplied with 2 SFP modules to complete a fully functional setup.

Click Here for Printer Friendly Version

NovaStar MX-Series Output Card with 1x 40G Fibre Features

- Sending card with 1x 40G QSFP+ SFP optical output
- Supports 8-, 10- and 12-bit colour depth
- Supports up to 17,694,720 pixels
- Supports Single Mode and Multi Mode fibre transmission

NovaStar MX-Series Output Card with 1x 40G Fibre Specifications

Outputs:
- Output Slots: 1

Optical:
- SFP Slot Type: 40G
- SFP Slot Quantity: 1

Extra Features:
- Scaling Function: Yes

Control and Programming:
- Maximum Loading Capacity: 17.6 Mpx
- Greyscale Processing: 12 bit

Mechanical Specifications:
- Weight: 0.5 kg (1.102 lb)
- IP Rating: IP20 (indoor use only)
- Colour: Black

Further Product Information Below

NovaStar MX2000 Pro Manual (PDF)

NovaStar MX6000 Pro Manual (PDF)

Please Note: This Item is to Order from NovaStar and is NON CANCELLABLE. If you require a lead time please contact us first before you place your order.
