NovaStar MX-Series Output Card with 4x 10G Fibre

Name: NovaStar MX-Series Output Card with 4x 10G Fibre
Brand: NovaStar
Price: 3964.94 GBP
Availability: InStock

Price Each £3,304.12 (£3,964.94 Including VAT at 20%)

REF: JP112550

Quantity:

NovaStar MX-Series Output Card with 4x 10G Fibre

The NovaStar MX-Series Output Card with 4x 10G Fibre is a fibre sending card for the Novastar MX Series main frames. It has four 10G optical output ports that support single and multi-mode fibre modules and a maximum transmission distance of 10 km. Each port has a load capacity of 10 1G Ethernet ports, and a single card supports up to 40x Ethernet port outputs. A single 1G Ethernet port has a maximum load of 659,722 pixels at 8-bit/60 Hz, which translates to 26,388,880 pixels for 40 1G ports. At 10/12-bit and 60 Hz, this drops to 329,861 pixels per port and 13,194,440 pixels in total.

Click Here for Printer Friendly Version

NovaStar MX-Series Output Card with 4x 10G Fibre Features

- Sending card with 4x SFP optical outputs
- Supports 8-, 10- and 12-bit colour depth
- Supports up to 26,388,880 pixels
- Supports Single Mode and Multi Mode fibre transmission

NovaStar MX-Series Output Card with 4x 10G Fibre Specifications

Outputs:
- Output Slots: 1

Optical:
- SFP Slot Type: 10G
- SFP Slot Quantity: 4

Extra Features:
- Scaling Function: Yes

Control and Programming:
- Maximum Loading Capacity: 26 Mpx
- Greyscale Processing: 12 bit

Mechanical Specifications:
- Weight: 0.8 kg (1.102 lb)
- IP Rating: IP20 (indoor use only)
- Colour: Black

Further Product Information Below

NovaStar MX2000 Pro Manual (PDF)

NovaStar MX6000 Pro Manual (PDF)

Please Note: This Item is to Order from NovaStar and is NON CANCELLABLE. If you require a lead time please contact us first before you place your order.
