NovaStar MX2000 Pro 8K LED Controller Main Frame for 35 Megapixels

Name: NovaStar MX2000 Pro 8K LED Controller Main Frame for 35 Megapixels
Brand: NovaStar
Price: 3842.52 GBP
Availability: InStock

Price Each £3,202.10 (£3,842.52 Including VAT at 20%)

REF: JP112539

Quantity:

NovaStar MX2000 Pro 8K LED Controller Main Frame for 35 Megapixels

The NovaStar MX2000 Pro is a professional 8K LED screen controller for large-screen rental services, xR/VP studios, TV productions, (e-)sports events, large fixed installations, etc. It supports true 12-bit colour depth, HDR, up to 360 Hz refresh rates, 0-frame latency, real-time multi-screen scaling and provides accurate brightness control, excellent colour and picture quality. There are several in- & output cards available which enable users to customise the processor to fit the needs of any project.

The MX2000 Pro can be controlled via its 5-inch touch screen in combination with the control knobs, via cascading Ethernet control and VMP software. It also supports the SNMP and Art-Net protocols. The control card is included, the input and output cards must be purchased separately.

Please Note: Only Armor A5s Plus and CX series receiver cards are supported. Older receiver cards like the MRV series are not supported.

Click Here for Printer Friendly Version

NovaStar MX2000 Pro Features

- Controls up to 35 million pixels
- Supports 2x Input card and 2x Output card
- Scaling function, 0-frame latency, frame rates up to 360 Hz
- True 12-bit, HDR, wide colour gamut, 3D display technology
- 5 inch LCD touch panel

NovaStar MX2000 Pro Specifications

Inputs:
- RS-232: 1
- Ethernet speed: 1 Gbit/s
- Input Slots: 2

Outputs:
- S/PDIF (Out): 1
- Output Slots: 2

Software Specifications:
- Control Software: VMP

Extra Features:
- Scaling Function: Yes
- Layers: 8
- GenLock: In & Out
- DMX Control: Art-Net

Control and Programming:
- Display: Touch
- Display Size: 5-inch
- Maximum Loading Capacity: 35.38 Mpx
- Control Options: Ethernet, RS232

Electrical Specifications and Connections:
- Power Supply: 100-240 V AC 50/60 Hz
- Power Consumption: 260 W
- Power Connector In: IEC
- Data Connector In: RJ45, USB
- Data Connector Out: RJ45

Mechanical Specifications:
- Dimensions (W x H x D):
- With Handles: 483 x 88 x 530 mm
- Without Handles: 440 x 88 x 530 mm
- Weight: 12 kg (26.455 lb)
- Rack Units: 2 U
- IP Rating: IP20 (indoor use only)
- Housing: Metal
- Colour: Black

Thermal Specifications:
- Maximum Ambient Temperature: 45 °C (113 °F)
- Operating Humidity: 0-80 %rH

Further Product Information Below

NovaStar MX2000 Pro Manual (PDF)

Please Note: This Item is to Order from NovaStar and is NON CANCELLABLE. If you require a lead time please contact us first before you place your order.

NovaStar MX2000 Pro Supplied With

- CAT-5 Cable
- IEC cable
