Seetronic SE8FF-02-C6A RJ45 CAT6A EtherCON Feedthrough Coupler - IP65

Seetronic SE8FF-02-C6A RJ45 CAT6A EtherCON Feedthrough Coupler Features

- CAT6a RJ45 feedthrough adapter for cable joining
- PoE++ support (IEEE 802.3bt) for combined power and data
- Compatible with Seetronic SE8MC-02-NEW connectors
- Short, compact, space-saving design
- IP65 rated for outdoor and industrial use
- Complies with TIA/EIA 568B and ISO/IEC 11801 CAT6a standards

Seetronic SE8FF-02-C6A RJ45 CAT6A EtherCON Feedthrough Coupler Specifications

- Connection Type: RJ45 Adapter
- Transmission Standard: CAT6a
- PoE Compatibility: PoE++ (IEEE 802.3bt)
- Contact Resistance: < 10 mΩ
- Rated Current: 2A
- Rated Voltage: 60V
- Insulation Resistance: ≥ 0.5GΩ
- Dielectric Strength: 1 KV DC
- Frequency Range: 1-100 MHz
- Insertion Force: ≤ 20 N
- Service Life: >1000 mating cycles
- Locking Device: Latch lock
- Contacts: Copper alloy, gold plated
- Insert: PBT
- Panel: Zinc alloy
- Operating Temperature: -30°C to +80°C
- Ingress Protection: IP65
- Standards: TIA/EIA 568B, IEC 11801

Further Product Information Below

Seetronic SE8FF-02-C6A Technical Drawing (PDF)
