Showtec Cameleon Spot Q4 RGBW LED Spot, 20W - IP65

Showtec Cameleon Spot Q4 RGBW LED Spot Features

- 15 W RGBW LED Spot
- IP65 (dust and water resistant, fit for outdoor use)
- 16° fixed beam angle
- Dimmer and strobe function
- Manual, DMX, IR and Master/Slave control

Showtec Cameleon Spot Q4 RGBW LED Spot Specifications

Source:
- Light Source Type: LED
- Light Source Quantity: 1
- Light Source Power: 15 W
- LED Colour Type: RGBW
- Refresh Rate (Max.): 12 kHz
- Luminous Flux (Total): 570 lm

Optical:
- Beam Angle (Circular): 16 °

Control and Programming:
- Control Mode: Auto, DMX, Master Slave
- DMX Channels: 4, 6, 10
- Protocols: DMX, RDM
- Display: OLED

Dynamic Effects:
- Dimmer: 0-100 %
- Strobe: 0-20 Hz

Electrical Specifications and Connections:
- Power Supply: 100-240 V AC 50/60 Hz
- Power Consumption: 20 W
- Power Connector In: Dedicated IP65 Powerconnection
- Power Connector Out: Dedicated IP65 Powerconnection
- DMX Connector: Dedicated 3P IP65 In/Out
- DMX Connector In: Dedicated 3P IP65
- DMX Connector Out: Dedicated 3P IP65
- Cable Length: 1.5 m

Mechanical Specifications:
- Length: 155 mm
- Width: 235 mm
- Height: 195 mm
- Weight: 2 kg (4.409 lb)
- IP Rating: IP65
- Housing: Aluminium
- Colour: Black

Product Properties:
- Cooling: Convection

Rigging:
- Mounting Options: Clamp

Further Product Information Below

Showtec Cameleon Spot Q4 Manual (PDF)

Showtec Cameleon Spot Q4 Data Sheet (PDF)

Showtec Cameleon Spot Q4 Declaration of Conformity (PDF)

Showtec Cameleon Spot Q4 RGBW LED Spot Supplied With

- Dedicated IP65 Power connection
- Bracket
