Showtec Compact Par 18 MkII RGB LED PARCan, 18x 3W - Black

Showtec Compact Par 18 MkII RGB LED PARCan Features

- Compact 18x 3 W RGB LED Par
- Double bracket for easy floor positioning
- Dimmer and strobe function
- Manual, DMX and Master/Slave control
- Auto run and Sound-controlled mode

Showtec Compact Par 18 MkII RGB LED PARCan Specifications

Source:
- Light Source Type: LED
- Light Source Quantity: 18
- Light Source Power: 3 W
- LED Colour Type: RGB
- Refresh Rate: 7800 Hz
- Illuminance @ 2 m: 3112 lx
- Luminous Flux (Total): 2323 lm

Optical:
- Beam Angle (Circular): 28 °

Control and Programming:
- Control Mode: Auto, Built-in Program, DMX, Master Slave, Sound
- DMX Channels: 1, 3, 4, 6
- Protocols: DMX
- Display: 7-segment

Dynamic Effects:
- Dimmer: 0-100 %
- Strobe: 0-20 Hz

Electrical Specifications and Connections:
- Power Supply: 100-240 V AC 50/60 Hz
- Power Consumption: 60 W
- Power Connector In: IEC
- Power Connector Out: IEC
- DMX Connector: XLR 3P In/Out
- DMX Connector In: XLR 3P
- DMX Connector Out: XLR 3P
- Cable Length: 1.5 m

Mechanical Specifications:
- Length: 250 mm
- Width: 290 mm
- Height: 96 mm
- Weight: 3 kg (6.614 lb)
- IP Rating: IP20 (indoor use only)
- Housing: Metal
- Colour: Black

Product Properties:
- Cooling: Convection

Rigging:
- Mounting Options: Clamp, Surface
- Safety Attachment: Yes

Thermal Specifications:
- Maximum Ambient Temperature: 40 °C (104 °F)
- Minimum Operating Temperature: -10 °C (14 °F)

Further Product Information Below

Showtec Compact Par 18 MkII Manual (PDF)

Showtec Compact Par 18 MkII Data Sheet (PDF)

Showtec Compact Par 18 MkII Declaration of Conformity (PDF)

Showtec Compact Par 18 MkII RGB LED PARCan Supplied With

- IEC cable
- Bracket
