Showtec Performer Profile 600 DDT WW LED Profile (Light Engine Only)

Name: Showtec Performer Profile 600 DDT WW LED Profile (Light Engine Only)
Brand: Showtec
Price: 859.15 GBP
Availability: InStock

Price Each £715.96 (£859.15 Including VAT at 20%)

REF: JP113979

Quantity:

Showtec Performer Profile 600 DDT WW LED Profile (Light Engine Only)

The Showtec Performer Profile 600 DDT WW LED Profile is a 250 watt Warm White COB LED ellipsoidal with high CRI and silent operations, suitable for theatrical applications. Its DDT-model (Direct triac Dimming Technology) is compatible with a conventional dimming infrastructure. The Performer Profile 600 features a 3200 K colour temperature and 0 - 100 % DMX controllable dimmer allowing a selection between 4 different curves. Optional industry standard fixed and zoom lenses allow a proper projection of hard-edge, precisely focused light where needed.

Click Here for Printer Friendly Version

Showtec Performer Profile 600 DDT WW LED Profile Features

- 250 W Warm White COB LED ellipsoidal
- Suitable for theatrical ans studio applications
- DDT-model compatible with a halogen infrastructure
- High CRI for accurate 3200 K colour rendering
- DMX dimmer function with 4 preset curves

Showtec Performer Profile 600 DDT WW LED Profile Specifications

Source:
- Light Source Type: LED
- Light Source Quantity: 1
- Light Source Power: 250 W
- LED Colour Type: WW
- Refresh Rate (Max.): 25 kHz
- Luminous Flux (Total): 10000 lm
- Maximum CCT: 3200 K

Control and Programming:
- Control Mode: DMX
- DMX Channels: 1, 2, 3
- Protocols: DMX
- Display: LCD
- Dim Curve: Linear, Square
- Dimmer Resolution: 16 bit

Dynamic Effects:
- Dimmer: 0-100 %

Electrical Specifications and Connections:
- Power Supply: 100-240 V AC 50/60 Hz
- Power Consumption: 270 W
- Power Connector In: powerCON Blue
- Power Connector Out: powerCON Grey
- DMX Connector: XLR 3P In/Out, XLR 5P In/Out
- DMX Connector In: XLR 3P, XLR 5P
- DMX Connector Out: XLR 3P, XLR 5P

Mechanical Specifications:
- Length: 720 mm
- Width: 380 mm
- Height: 340 mm
- Weight: 9.6 kg (21.164 lb)
- IP Rating: IP20 (indoor use only)
- Housing: Aluminium die-cast
- Colour: Black

Product Properties:
- Cooling: Convection/Axial fan

Thermal Specifications:
- Maximum Ambient Temperature: 80 °C (176 °F)
- Maximum Surface Temperature: 45 °C (113 °F)
- Minimum Operating Temperature: -10 °C (14 °F)

Further Product Information Below

Showtec Performer Profile 600 DDT Manual (PDF)

Showtec Performer Profile 600 DDT Data Sheet (PDF)

Showtec Performer Profile 600 DDT Declaration of Conformity (PDF)

Showtec Performer Profile 700 Q6 RGBALC LED Profile Supplied With

- PowerCON Cable

Please Note: This listing includes the Light Engine only. The Lens Tube and accessories are sold separately.
