Walther 230SW 32A 415V 3P+N+E Black Plug

Name: Walther 230SW 32A 415V 3P+N+E Black Plug
Brand: Walther
Price: 38.66 GBP
Availability: InStock

Price Each £32.22 (£38.66 Including VAT at 20%)

REF: JP112399

Quantity:

Walther 230SW 32A 415V 3P+N+E Black Plug

The Walther 230SW 32A 415V 3P+N+E Black Plug is a heavy-duty 32A 5-pin 400V industrial plug engineered for demanding lighting and stage environments. Designed with a 6h clock position and splashproof IP44 rating, this robust black PA6 housing plug features screw terminals, an external swivel cable gland, and an internal grommet for secure, reliable cable entry. With enhanced safety from an injected 2K seal and dual contact screws, this plug ensures professional-grade power distribution for event production, touring, and industrial applications.

Click Here for Printer Friendly Version

Walther 230SW 32A 415V 3P+N+E Black Plug Features

- 32A IEC current rating
- 5-pin configuration (3P+N+E)
- 400V, 50/60Hz
- 6h clock position (red identification)
- IP44 splashproof protection
- Durable black PA6 plastic housing
- Screw terminal connections with dual screws for security
- External swivel cable gland and internal grommet for strain relief
- Injected 2K seal for increased safety and reliability
- Straight design with anti-kink protection

Walther 230SW 32A 415V 3P+N+E Black Plug Specifications

- Part number: 230SW
- Poles: 5 (3P+N+E)
- Voltage: 400V AC (50/60Hz)
- Current: 32A IEC
- Degree of protection: IP44
- Clock position: 6h
- Material: PA6 plastic, black
- Connection: Screw terminal with internal grommet
- Cable entry: External swivel cable gland, 10-22.5mm diameter
- Conductor cross-section: 2.5-6mm²
- Cable strip length: 45mm ±2.5mm
- Cable ferrule length: 10mm ±1mm
- Torque terminal screw: 0.8Nm
- Torque cable gland: 4Nm
- Inflammability class: UL94 V2
- Net weight: 0.3001kg

Further Product Information Below

Walther 230SW Data Sheet (PDF)
