Ecler DROP6i 6.5-Inch 2-Way IP53 Pendant Speaker, 75W @ 8 Ohms or 70V / 100V Line - White

Name: Ecler DROP6i 6.5-Inch 2-Way IP53 Pendant Speaker, 75W @ 8 Ohms or 70V / 100V Line - White
Brand: Ecler
Price: 269.57 GBP
Availability: InStock

Price Each £224.64 (£269.57 Including VAT at 20%)

REF: JP115381

Quantity:

Ecler DROP6i 6.5-Inch 2-Way IP53 Pendant Speaker, 75W @ 8 Ohms or 70V / 100V Line - White

The Ecler DROP6i 6.5-Inch 2-Way IP53 Pendant Speaker is a 2-way full-range 6.5-inch pendant loudspeaker delivering 75W @ 8Ω, designed with a sleek, discreet aesthetic. It features a 70/100V line transformer with selectable 60/30/15/7.5W power taps and is available in both high- and low-impedance configurations.

Click Here for Printer Friendly Version

Ecler DROP6i 6.5-Inch 2-Way IP53 Pendant Speaker Features

- Two-way full-range pendant loudspeaker
- 75W RMS @ 8Ω
- 6.5-inch woofer / 1-inch Silk Dome tweeter
- Compatible for use in high impedance (70V or 100V line) and low impedance (8Ω)
- Power selector: 4 options of 60W/30W/15W/7.5W in high impedance or one 75W option in low impedance
- IP53 rated
- ABS reinforced with fibreglass
- Paintable grille
- INPUT/LINK double connector, Euroblock type
- Cable length: 5m (includes 2 height adjustable steel cords)
- Available in white (RAL9003) and black (RAL9005)
- EASE files available

Ecler DROP6i 6.5-Inch 2-Way IP53 Pendant Speaker Specifications

System:
- Effective Freq. Range: 70Hz -20KHz (-10dB)
- Coverage angle / Dispersion: 135° Conical
- Power handling: 75W RMS / 300W Peak
- Sensitivity: 90dB (1W/1m)
- Maximum SPL: 109dB continuous / 115dB peak
- Power options (Hi Z Multi-tap): 70V/100V: 7.5W - 15W - 30W - 60W / 75W @ 8Ω
- Recommended amplifier power: 150W RMS

Drivers:
- Ways: 2-ways full range
- Driver: 6.5-inch Woofer + 1-inch Tweeter
- Low frequency driver: 6.5-inch Woofer
- High frequency driver: 1-inch Silk Dome Tweeter
- Nominal impedance: 8Ω

Filters:
- Crossover filter: 1.65 KHz

Physical:
- Connection type: Double INPUT/LINK connector, Euroblock type
- Power type selector: Back panel tap rotary selector
- Installation options: Pendant
- Environmental: IP53 rated
- Enclosure material: ABS reinforced with fibreglass
- Grille material: Aluminium
- Grille fixing system: Bayonet mount system
- Mounting system: Steel wire hanging
- Flying points: 2x Steel wire hanging points
- Operating temperature: Min: -20°C ; -4°F Max: 70°C ; 158°F
- Operating humidity: <85% HR
- Storage temperature: Min: -20°C ; -4°F Max: 70°C ; 158°F
- Storage humidity: <90% HR
- Finished colour: White (RAL9003)
- Dimensions (Ø x H): 270 mm x 344 mm
- Weight: 4.2 Kg
- Pieces per box: 1

Further Product Information Below

Ecler DROP6i Manual (PDF)

Ecler DROP6i Data Sheet (PDF)

Ecler DROP6i Technical Drawing (PDF)

Ecler DROP6i 6.5-Inch 2-Way IP53 Pendant Speaker Supplied With

- 1x Ecler CDROP6IWH
- 2x Steel Wire for hanging (5m)
- 2x 3C Euroblock connector
