Ecler IC8i 8-Inch 2-Way Ceiling Speaker, 60W @ 8 Ohms or 70V / 100V Line - White (Pair)

Ecler IC8i 8-Inch 2-Way Ceiling Speaker Features

- Two-way ABS speaker, 60W RMS
- 8-inch woofer / 1-inch dome tweeter
- Built-in audio transformer for 70/100V use
- Polypropylene woofer that resists heat and humidity
- Frameless Magnetic grill
- Front grill may be removed for painting
- The Ecler logo is removable
- Clip-type input terminals and low impedance / high impedance power tap selector
- Cutting template included
- Support system with 3 rotating tabs
- Available in black (RAL9005) or white (RAL9003) finish
- EASE files available

Ecler IC8i 8-Inch 2-Way Ceiling Speaker Specifications

System:
- Effective Freq. Range: 65Hz-20kHz (-10dB)
- Coverage angle / Dispersion: 152° conical
- Power handling: 60W RMS / 240W Peak
- Sensitivity: 94dB (1W/1m)
- Maximum SPL: 112dB continuous / 118dB peak
- Power options (Hi Z Multi-tap):
  - 70V: 2.5 / 3.75 / 7.5 / 15W
  - 100V: 5 / 7.5 / 15 / 30W
- Recommended amplifier power: 120W RMS

Drivers:
- Ways: 2-ways full range
- Low frequency driver: 8-inch Woofer
- High frequency driver: 1-inch Dome Tweeter
- Nominal impedance: 8Ω

Physical:
- Connection type: Clip-Type input terminals
- Installation options: In-ceiling / In-wall
- Enclosure material: ABS plastic
- Grille material: Iron
- Grille fixing system: Magnets
- Mounting system: 3 rotating tabs
- Operating temperature: Min: -20°C ; -4°F Max: 70°C ; 158°F
- Operating humidity: <85% HR
- Storage temperature: Min: -20°C ; -4°F Max: 70°C ; 158°F
- Storage humidity: <90% HR
- External diameter: 254 mm
- Internal diameter: 219 mm
- Recommended cut out diameter: 222 mm
- Required depth: >94 mm
- Finished colour: White (RAL 9003)
- Dimensions: 254 x 254 x 93 mm
- Weight: 2.35 Kg
- Pieces per box: 2

Further Product Information Below

Ecler ICi-Series Manual (PDF)

Ecler IC8i Data Sheet (PDF)

Ecler IC8i Technical Drawing (PDF)

Ecler IC8i 8-Inch 2-Way Ceiling Speaker Supplied With

- 2x Ecler CIC8iWH
- 1x Cutting template
