Crown CT475 300W ComTech DriveCore Amplifier

Crown CT475 300W ComTech DriveCore Amplifier

Crown CT475 300W ComTech DriveCore Amplifier

Price Each 672.30 Exc VAT or (806.76 Inc VAT at 20%)

For Install and Dealer Volume prices please contact us.

Need to Price Match it ? Click Here to see what we can do.

Ref: JP8095


Click Here For PDF User Manual

Crown CT475 300W ComTech DriveCore Amplifier, Crown's ComTech CT-475 amplifier delivers studio-grade sound in one rack-space with 4 channels of 75W. Performance is exemplary in every respect with Signal-to-Noise of better than 110dB and Total Harmonic Distortion below 0.05% across the full audio bandwidth.

Powering this remarkable amplifier is the pioneering technology of DriveCore, a chip built exclusively for Harman which replaces 500 individual components of previous designs, seamlessly integrating the amplifier drive stage into the power output. The end result is an ultra-energy efficient, highly reliable, one-piece audio amplifier circuit that exhibits the exemplary audio quality of a highly evolved Class AB design.


  • A signal-to-noise ratio of better than 110dB
  • Total harmonic distortion below 0.05% across the full audio bandwidth
  • Greater than 70dB crosstalk
  • Frequency response of 0.5dB
  • Up to 8 channels in a single rack-space
  • Weight of only 10 pounds (4.54 Kg)
  • Over 90% efficient in the DriveCore amplifier stage
  • Power consumption of less than 1W when not in use (In Deep Sleep)
  • Green Mode delivers power when needed. Amplifier efficency increases by up to 10% when compared to typical class D amplifiers
  • 4 channel or 8 channel (4 inputs with 4 outputs or 8 inputs with 8 outputs)
  • Single rack space
  • Balanced 3-pin Barrier block-type/line inputs
  • 4-pin Phoenix-type speaker outputs
  • Flexible input routing
  • Multiple Power Configuration (Auto-Standby, Deep Sleep, and Green Mode)
  • Auxiliary port for amp status and power saving mode (Deep Sleep)
  • Circuit breaker protection with reset switch
  • Convection-cooled chassis (no fan)
  • Three-year, no-fault, fully transferable warranty that completely protects your investment and guarantees its specifications
  • Can be used in mass notification and EN 54 systems
  • Patented technology including DriveCoreTM
  • Fault Reporting through Aux Port
  • Adaptive Rail Technology for power on demand.
  • Complies with Green Edge by Harman


  • Channels: 4
  • Sensitivity: 1.4V
  • Rated Power Output:
    • 75W per CH @ 8 ohms
    • 75W per CH @ 4 ohms
  • Signal to Noise Ratio (below rated power 20Hz to 20kHz, A-Weighted): 110dB
  • Total Harmonic Distortion (THD) (full rated power, 20Hz - 20kHz): < 0.05%
  • Intermodular Distortion (from 0dB down to -40dB): < 0.05%
  • Frequency Response (at 1W into 4/8 ohms): 0.5dB
  • Crosstalk (below rated power 20Hz to 1kHz): > 70dB
  • Common Mode Rejection (20Hz to 1kHz): > 55dB, typically > 70dB
  • Dimensions (H x W x D): 1.75" x 19" x 14.25"
  • Net Weight:10 lbs/4.54 kg
