Hollyland Pyro H-RX Wireless 4K Video Receiver

Hollyland Pyro H-RX Wireless 4K Video Receiver Features

- HDMI and SDI video outputs
- USB-C UVC output for plug-and-play livestreaming
- Supports up to 4K30 HDMI and 1080p60 SDI
- Dual-band 2.4GHz/5GHz transmission up to 1,300ft
- Low latency monitoring (~60ms typical)
- Supports Broadcast mode with multiple receivers
- Compatible with Hollyland Pyro S Transmitter only
- Powered via DC input, NP-F battery, or USB-C (excluding Broadcast mode)

Hollyland Pyro H-RX Wireless 4K Video Receiver Specifications

- Outputs: HDMI, SDI, USB-C UVC
- Input: Signal received from Pyro S Transmitter
- Resolution Support: 720p to 4K30 via HDMI; up to 1080p60 via SDI
- Latency: ~60ms
- Wireless Band: 2.4GHz + 5GHz dual band
- Range: Up to 1,300ft (650ft in Broadcast mode)
- Power: DC 6-16V, NP-F battery, USB-C 5V 2A
- Power Consumption: Approx. 4W
- Dimensions: 109 x 62.3 x 33.4mm
- Weight: 192g

Further Product Information Below

Hollyland Pyro H-Series Manual (PDF)

Hollyland Pyro H-Series Data Sheet (PDF)

Hollyland Pyro H-Series Quick Reference Guide (PDF)
