Hollyland Pyro H-TX Wireless 4K Video Transmitter

Hollyland Pyro H-TX Wireless 4K Video Transmitter Features

- HDMI 1.4b input and loop-out, plus SDI input
- USB-C UVC output for streaming to computers
- Supports 4K up to 30fps and HD up to 1080p60
- Up to 1,300ft wireless range (650ft in Broadcast mode)
- Latency under 60ms with automatic frequency selection
- Compatible with up to 2 RX units or 4 HollyView app devices
- Multiple power options: DC, NP-F battery, USB-C (excluding Broadcast mode)
- Scene modes: HD, Balanced, Speed

Hollyland Pyro H-TX Wireless 4K Video Transmitter Specifications

- Inputs: HDMI (input + loop-out), SDI
- Output: USB-C UVC
- Resolution Support: 720p to 4K30 via HDMI; up to 1080p60 via SDI
- Latency: ~60ms
- Wireless Band: 2.4GHz + 5GHz dual band
- Range: Up to 1,300ft (650ft in Broadcast mode)
- Power: DC 6-16V, NP-F battery, USB-C 5V 2A
- Power Consumption: Approx. 7W
- Dimensions: 109 x 62.3 x 33.4mm
- Weight: 192g

Further Product Information Below

Hollyland Pyro H-Series Manual (PDF)

Hollyland Pyro H-Series Data Sheet (PDF)

Hollyland Pyro H-Series Quick Reference Guide (PDF)
