NovaStar ET2S-G Media Server

Name: NovaStar ET2S-G Media Server
Brand: NovaStar
Price: 1845.42 GBP
Availability: InStock

Price Each £1,537.85 (£1,845.42 Including VAT at 20%)

REF: JP112551

Quantity:

NovaStar ET2S-G Media Server

The NovaStar ET2S-G Media Server is designed for small to medium rental or fixed installation applications. Offering 8K x 2K output capacity, the ET2S-G supports up to 1x DP 1.2 and 2x HDMI 2.0 mosaic outputs to easily drive creative mosaic displays on irregular screens. Splitting, merging and rotating are supported, and a single output can be split into up to 64 partitions, allowing for quick mapping settings and ultra-wide screen configurations. Up to 8 layers and 1 audio stream can be played back simultaneously.

The included Kompass FX2 software ensures seamless, ultra-clear and smooth video playback with support for common video formats including H.264, H.265, MPEG-4/2, WMV and VP9. Four USB 3.0 and two USB 2.0 ports provide fast external storage and mouse/keyboard connectivity. The software offers user-friendly media library management and supports PowerPoint files, NDI sources, website sources, streaming media and text sources. Its intuitive and user-friendly interface makes it easy to control content playback. NovaStar's Visual Intelligent Control Platform (VICP) allows remote playback control as well.

Click Here for Printer Friendly Version

NovaStar ET2S-G Media Server Features

- Max. output resolution: 4096 x 2160 @60 Hz
- Mosaic output support for all outputs
- Supports up to 16384 pixels width or height
- Kompas FX2 software license included (dongle)
- NDI support

NovaStar ET2S-G Media Server Specifications

Inputs:
- Mono Inputs: 1
- Mono Input Connector: TS unbalanced 3.5 mm
- Stereo Inputs: 1
- Stereo Input Connector: TRS balanced 3.5 mm

Outputs:
- DP 1.2 (out): 1
- HDMI 2.0 (Out): 2
- HDMI (for Control): 1
- USB 2.0: 2
- USB 3.0: 4
- Stereo Outputs: 1
- Stereo Outputs (type): TRS balanced 3.5 mm

Control and Programming:
- Output Resolution: 4096 x 2160
- NDI Supported: Yes

Software Specifications:
- Supported Layers: 8

Playback:
- Processor: 12th Generation Intel Core

Server Specifications:
- AV Software Included: Yes
- AV Software Package: Kompas FX2
- Memory Type: DDR4
- Memory Size: 16 GB
- Storage 1 Type: SSD
- Storage 1 Size: 500 GB
- Maximum Resolution Width: 16384 px
- Maximum Resolution Height: 16384 px

Electrical Specifications and Connections:
- Power Supply: 100-240 V AC 50/60 Hz
- Power Consumption: 400 W
- Power Connector In: IEC
- Data Connector: RJ45 In/Out, USB

Mechanical Specifications:
- Dimensions (W x H x D):
- With handles: 483 x 95 x 581 mm
- Without handles: 440 x 88 x 535 mm
- Weight: 10 kg
- Rack Units: 2 U
- IP Rating: IP20 (indoor use only)
- Colour: Black

Product Properties:
- Cooling: Active

Thermal Specifications:
- Maximum Ambient Temperature: 45 °C (113 °F)
- Operating Humidity: 0-80 %rH

Further Product Information Below

NovaStar ET2S-G Manual (PDF)

Please Note: This Item is to Order from NovaStar and is NON CANCELLABLE. If you require a lead time please contact us first before you place your order.

NovaStar ET2S-G Media Server Supplied With

- DP-DP cable
- HDMI-HDMI cable
- IEC cable
- Keyboard (USB)
- Mouse (USB)
